40 Haltech ESP Keyboard Shortcuts
Learn Haltech ESP Shortcuts for Windows
Most Used Haltech ESP Shortcuts
| Action | Haltech ESP Shortcuts |
|---|---|
| Increase Cell Value | Page Up Key |
| Decrease Cell Value | Page Down Key |
| Small Increase of Cell Value | Ctrl + Page Up Key |
| Small Decrease of Cell Value | Ctrl + Page Down Key |
| Large Increase of Cell Value | Shift + Page Up Key |
| Large Decrease of Cell Value | Shift + Page Down Key |
| Set the Tuning Table cell value | 0 – 9 |
| Moves the selected cell(s) pointer | Arrow Keys |
| Increases the number of selected cells | Shift + Arrow Keys |
| Decreases the number of selected cells | Ctrl + Arrow Keys |
| Change the selected map | Alt + Arrow Keys |
| Selects the next Tuning Page | Tab |
| Selects the previous Tuning Page | Shift + Tab |
| Aligns the cursor to current engine operating point | Spacebar |
| Shrinks the selection to a single cell | Ctrl + Spacebar |
| Open Help Window | F1 |
| Axes Setup | F3 |
| Main Setup | F4 |
| Connect / Disconnect from ECU | F5 |
| Start/Stop Recording PC Datalogging | F6 |
| Enter/Exit Datalog Playback Mode | F7 |
| Play/Pause Currently Loaded Datalog – Playback Mode Only | F8 |
| Full Screen Mode | F11 |
| Select all the cells in the current Tuning Table | Ctrl + A |
| Copy | Ctrl + C |
| Paste | Ctrl + V |
| Reboot ECU | Ctrl + F12 |
| Percentage increase or decrease the selected cells | P |
| Linearize across the selected cells | L |
| Enables/Resets/Disables Trace in Text View | T |
| To insert a Row/Column in Tuning Table | Insert |
| To delete a Row/Column in Tuning Table | Delete |
| Moves the selected cell(s) to the Left of the Tuning Table | Home |
| Moves the selected cell(s) to the Right of the Tuning Table | End |
| Copy the current Tuning Table value to an adjacent cell. | Ctrl + Shift + Arrow Keys |
| Tab page shortcut. If the shortcut does not exist, the current tab will be assigned the shortcut. | Ctrl + Shift + A – Z |
| Toggle All Ranges Mode of selection. | R |
| Toggle All Ranges Above mode of selection. Only available when All Ranges Mode is enabled. | A |
| Performs Quick Tune Function on the cell currently used by the ECU. Only available when a Wideband O2 Sensor is enabled | Q |
| Performs Quick Tune Function on the cell currently used by the ECU as well as the cells higher in RPM and Load. Only available when a Wideband O2 Sensor is enabled. | W |
