29 OrCAD Capture Keyboard Shortcuts
OrCAD Capture is a powerful tool for designing and simulating electronic circuits. To maximize efficiency and productivity it’s essential to master the OrCAD Capture shortcuts. These shortcuts enable designers to perform tasks quickly, accurately, and with minimal effort.
Table of Contents
We’ll explore the most useful OrCAD Capture Shortcuts that can streamline your design process and improve your overall workflow.
Most Used OrCAD Capture Shortcuts
| Action | OrCAD Capture Shortcuts |
|---|---|
| Rotate | R |
| Help | F1 |
| Exit | Alt + F4 |
| Copy | Ctrl + C |
| Paste | Ctrl + V |
| Cut | Ctrl + X |
| Find | Ctrl + F |
In schematic shortcuts
| Action | OrCAD Capture Shortcut keys |
|---|---|
| Place bus | B |
| Place bus entry | E |
| Place power | F |
| Place ground | G |
| Place junction | J |
| Place net alias | N |
| Place net group | U |
| Place part | P |
| Place database part | Z |
| Place wire | W |
| Place no connect | X |
| Place text | T |
| Ascend hierarchy | Shift + A |
| Descend hierarch | Shift + D |
Schematic & Part Editor Shortcuts
| Action | OrCAD Capture Shortcut Keys |
|---|---|
| Edit properties | Ctrl + E |
| Save | Ctrl + S |
| Redo | Ctrl + Y |
| Undo | Ctrl + Z |
| Repeat | F4 |
| Deselect | Esc |
| Zoom in | I |
| Zoom out | O |
Mastering OrCAD Capture hotkeys can significantly enhance your design experience and productivity. By incorporating these shortcut keys into your workflow, you’ll be able to work more efficiently, reduce errors, and focus on the creative aspects of circuit design.
With practice and familiarity, these OrCAD Capture Shortcut keys will become second nature, allowing you to unlock the full potential of OrCAD Capture. By leveraging these OrCAD Capture Shortcut keys, you’ll be able to design and simulate electronic circuits with ease, accuracy, and speed.
